Box-drawing characters, also known as line-drawing characters, are a form of semigraphics widely used in text user interfaces to draw various geometric frames and boxes. In graphical user interfaces, these characters are much less useful as it is much simpler to draw lines and rectangles directly with graphical APIs. Box-drawing characters work only with monospaced fonts; however, they are still useful for plaintext comments on websites.

Used along with box-drawing characters are block elements, shade characters, and terminal graphic characters. These can be used for filling regions of the screen and portraying drop shadows.

Products :: Print/Mat boxes - Bookeh Books | Flush mount albums ...
bookehbooks.com



Encodings

Unicode

Unicode includes 128 such characters. In many Unicode fonts only the subset that is also available in the PC character set (see below) will exist, due to it being defined as part of the WGL4 character set.

DOS

The original IBM PC supplied the following box-drawing characters, in what MS-DOS now calls code page 437. This subset of the Unicode box-drawing characters is thus far more popular and likely to be rendered correctly:

Their number is further limited to 22 on those code pages that replace the 18 "single/double hybrid" characters for other, usually alphabetic, characters (such as code page 850):

Note: The non-double characters are the "thin" ones (U+2500, U+2502), not the "wide" ones (U+2501, U+2503).

Unix, CP/M, BBS

On many Unix systems and early dial-up bulletin board systems the only common standard for box-drawing characters was the VT100 alternate character set. The escape sequence Esc ( 0 switched the codes for lower-case ASCII letters to draw this set, and the sequence Esc ( B switched back:

A Bash script that displays all of the semigraphic characters:

On some terminals, these characters are not available at all, and the complexity of the escape sequences discouraged their use, so often only ASCII characters that approximate box-drawing characters are used, such as - (hyphen-minus), | (vertical bar), _ (underscore), = (equal sign) and + (plus sign) in a kind of ASCII art fashion.

Modern Unix terminal emulators use Unicode and thus have access to the line-drawing characters listed above.

Historical

Many microcomputers of the 1970s and 1980s had their own proprietary character sets, which also included box-drawing characters. Some of these sets, such as Commodore's PETSCII, include box-drawing symbols with no corresponding Unicode character.

The Sinclair ZX81 and Spectrum included a set of text semigraphics with block elements and dithering patterns.

The BBC Micro could utilise the Teletext 7-bit character set, which had 128 box-drawing characters, whose code points were shared with the regular alphanumeric and punctuation characters. Control characters were used to switch between regular text and box drawing.

MouseText is a set of display characters for the Apple IIc, IIe, and IIgs that includes box-drawing characters.

Some recent embedded systems also use proprietary character sets, usually extensions to ISO 8859 character sets, which include box-drawing characters or other special symbols.

The World Standard Teletext (WST) uses pixel-drawing characters for some graphics. A character cell is divided in 2×3 regions, and 26 = 64 code positions are allocated for all possible combinations of "pixels". However, these characters are not included in the Unicode standard.

Print Boxes Video




Examples

Sample diagrams made out of the standard box-drawing characters, using a monospaced font:

  +-++  ????  ?-??  ????  | ||  ? ??  ? ??  | ||  +-++  ????  ?-??  ????  +-++  ????  ?-??  ????  +-------------------+  |  ????? Some Text  |?  |  ????? in the box |?  ??????????????????????  | +--+--+           |?  | +--+--+           |?  +-------------------+?   ?????????????????????
